Most drilling rigs have fully automated derrick and pipe handling systems. In certain regions the legislation prohibits personnel to work on the drill floor while the automatic pipe handling machines are in use. But still we experience personnel using HP cleaners and manual dope brushes when drill pipe and other tubulars are cleaned and doped prior to connection.
Facts
The COBRA can be installed in two different ways - stand alone or integrated with the pipe handling system. It can we tailor-made to fit most drill floor applications and to be used with most types of pipe handling equipment
As stand alone the COBRA is placed conveniently on the drill floor. When the DP moves from setback area towards well center the pipe handler makes a wash and dope stop. The COBRA will raise vertically and position itself embracing the DP pin end. After engaging a 360 degree sequence using HP water will wash the threads and apply dope. After a few seconds the DP can move on.
When integrated the COBRA is installed on the pipe handler/racker. The COBRA will raise to engage with the pin end and to carry out the wash and dope sequence.
Wash time and applied dope volume are PLC controlled parameters. The COBRA require power, HP water, air and dope to operate. It is ATEX certified, Zone 1, CE certification, etc. Optional choices are:
Dope pump stand alone. Data tracker and heat tracing available.
HP Wash Down Unit, integration available.
Supply station. Dope pump and HP Cleaner build into cabinet.
Advantages
Easy to install on the drill floor or pipe handler.
The COBRA will wash and dope the DP tool joints automatically and ensure clean threads before applying correct amount of dope.
Air-driven cylinder ensures gentle tool interaction with DP. Self-cleaning interior wash/flush sequence. Drain hose connection, no spill on drill floor. No personnel in drop zone while tripping in hole.
Benefits
Releases human resources. Personnel avoid the danger of dropped objects or working close to remote operated machines on drill floor (Red Zone).
No over torqued connections. Not taking up iron roughneck time (as when pipe doper is installed on iron roughneck).
We can provide a suitable HP Cleaner for your MONSOON Shaker Screen Washer / COBRA Wash & Dope Tool / TYPHOON Wiper / BHA Wash Tool / SPEEDY Gonzales Pin Cleaner.
The ROUGHNECK BACKSAVER is a power slips lifter which eliminates the need of manual handling of heavy slips. It can be operated from the driller’s console or at a safe distance.
Facts
The BACKSAVER Slips Lifter can be hydraulic or pneumatic operated as per customer requirements.
Advantages
Easy and quick to install.
Benefits
Personnel is kept out of Red Zone. Personnel will not have to lift heavy slips which is safer and more efficient. The number of personnel required on the rig floor is reduced.
Many rigs are still equipped with manual mud pump fluid end caps. These caps are usually tightened and loosened by use of sledgehammer.
Facts
Made of stainless steel. Tailor-made to fit any fluid end caps.
Rigtools can also provide a hydraulic or pneumatic torque wrench fit for purpose.
Advantages
The PITBULL Torque Tool eliminates use of sledgehammer. Correct and controlled torque is applied when making up end caps.
Benefits
Use of sledgehammer is a potential hazard to personnel and causes accidents while handling mud pump fluid end caps. This hazard is eliminated by using PITBULL Torque Tool. In addition it is more gentle to the equipment.
All Speedy cleaning tools are designed to ease daily HP cleaning operations on
the drill floor. Depending on preference the tools can be used with HP water or air
Facts
4 x different specialized cleaning tools available. Made from high quality Stainless steel. Ensures HP Cleaning operations for various tubular handling tasks are performed in the most efficient manner.
Advantages
The operator using Speedy Cleaners spends only a few seconds to clean pin or box threads 360 degrees, Iron Roughneck dies or various wireline tools in one workflow
Benefits
Increase efficiency and reduces exposure of personnel in Red Zone.
The operator works in a safe distance with the tool intended for the specific operation.
THE SPEEDY FAMILY
• Speedy Pin Cleaner (Also available with 90 degree and 45-degree bends)
– Used for drill pipe pins.
• Speedy Pin Cleaner XL (Also available with 90 degree and 45-degree bends).
Bigger ID for cleaning casing. Has also been used with success when cleaning wireline tools when coming out of the hole.
• Speedy Die Cleaner, 3-way nozzles spaced at 120 degrees for efficient cleaning of Iron Roughneck dies.
• Speedy Box Cleaner
– Rotating head on lance for cleaning Casing and Drill Pipe boxes.
• Speedy Cabinet, contains the full set of Speedy cleaners.
Video
We can provide a suitable HP Cleaner for your MONSOON Shaker Screen Washer / COBRA Wash & Dope Tool / TYPHOON Wiper / BHA Wash Tool / SPEEDY Gonzales Pin Cleaner.
When handling lifting subs homemade tools or straps are often used. Handling lifting subs in various ways have caused many incidents and pinched fingers.
Facts
Made of stainless steel. We supply RIGTOOLS Clamp in following standard sizes:
3 ½"
4"
5"
5 ½"
5 ⅞"
6 ⅝"
7"
Two-legged lifting sling and full certification for offshore use is included.
Advantages
RIGTOOLS Clamp is clamped directly around the lifting subs when installing or removing them from BHA components. The safety hooks keep the RIGTOOLS Clamp securely locked while in operation.
No loose bolts or shackles required, no need of slings for handling lifting subs.
Benefits
RIGTOOLS Clamps makes operation more safe and efficient when handling lift subs in vertical and especially horizontal position. The handling is in control and keeps hands and fingers free from danger. The risk of hanging up in threads when removing lifting subs in vertical position is reduced.
Reviews
I am a Directional Driller in the UK sector of the North Sea, currently working on BP Clair project.
I have seen your clamp used on several other rigs (most recently the ENSCO 100) in the North Sea and always try to convince clients of the safety but also efficiency merits of this piece of equipment, especially when installing/removing lifting subs in the horizontal position.Craig Beaton, Directional Driller -- SCHLUMBERGER OILFIELD UK PLC
The Rigtools Clamps make handling of our lifting subs safer and easier , no more wrapping slings round subs, quick and easy installation of the clamp either vertically or horizontally, no shackles bolts or safety pins to worry about, the subs are held securely and rotate easily so installing into collars etc made safer with little chance of nipped or crushed fingers when using chain tongs. We have a 5½” and 5” Rigtools clamp, two of the best additions to drill floor safety and efficiency we have had. Best Regards, Alistair -- MAERSK CONVINCER
We have been using your ‘Rigtool Clamps’ for some time now and are very happy with the product.
Excellent tool for eliminating the drop sub hazards.Will Sellens, Drilling Section Leader -- SEADRILL WEST GEMINI
I am a drilling section leader on the West Aquarius drilling vessel. We recently purchased a sub clamp lift tool for use on our rig working in Canada.
We have had great success in both efficiency and safety in handling these subs. We have shared this experience across our fleet of Seadrill rigs and also our client, Exxon mobil has shared it through out their companyJosh Allen, Drilling Section Leader -- SEADRILL WEST AQUARIUS
We are using the the tool every day and find it greatJohn Ralph Drilling Section Leader West Aquarius
Rental
We can provide rental of RIGTOOLS Clamps. All RIGTOOLS Clamp comes with a chain sling
Standard sizes for both On- and Offshore rigs are stock item.
It is possible to custom make RIGTOOLS Clamps to non standard sizes.
Delivery time for standard sizes: Stock Item.
Video
Statements
The Rigtools Clamps make handling of our lifting subs safer and easier , no more wrapping slings round subs, quick and easy installation of the clamp either vertically or horizontally, no shackles bolts or safety pins to worry about, the subs are held securely and rotate easily so installing into collars etc made safer with little chance of nipped or crushed fingers when using chain tongs. We have a 5½” and 5” Rigtools clamp, two of the best additions to drill floor safety and efficiency we have had. Best Regards, Alistair -- MAERSK CONVINCER
I am a drilling section leader on the West Aquarius drilling vessel. We recently purchased a sub clamp lift tool for use on our rig working in Canada.
We have had great success in both efficiency and safety in handling these subs. We have shared this experience across our fleet of Seadrill rigs and also our client, Exxon mobil has shared it through out their companyJosh Allen, Drilling Section Leader -- SEADRILL WEST AQUARIUS
We are using the the tool every day and find it greatJohn Ralph Drilling Section Leader West Aquarius
We have been using your ‘Rigtool Clamps’ for some time now and are very happy with the product.
Excellent tool for eliminating the drop sub hazards.Will Sellens, Drilling Section Leader -- SEADRILL WEST GEMINI
I am a Directional Driller in the UK sector of the North Sea, currently working on BP Clair project.
I have seen your clamp used on several other rigs (most recently the ENSCO 100) in the North Sea and always try to convince clients of the safety but also efficiency merits of this piece of equipment, especially when installing/removing lifting subs in the horizontal position.Craig Beaton, Directional Driller -- SCHLUMBERGER OILFIELD UK PLC
The high level of safety in today's drilling operations requires special attention to clean work areas and mud exposures. To increase safety and prevent personnel being exposed to mud and chemicals, we have introduced the automatic MONSOON Shaker Screen Washer.
Facts
Made of stainless steel and quality components.
Fast efficient cleaning of multi-size screens. MONSOON is fully certified for offshore conditions; ATEX Zone 1, NORSOK and CE certification.
It require sufficient supply of HP Water, air and power.
Advantages
Special nozzle system creates dynamic impact. Small footprint. The machine has isolating inner and outer housing.
100 % control with critical substances. Mud and cuttings will be drained. Vapors will leave through exhaust pipe.
Benefits
Consistent and gentle wash sequence will prolong screen lifetime significantly and reduce your cost.
Crew will not be exposed to mud and noise level is reduced. The risk of exposure to hot water and hot surfaces f using hot water is eliminated.
Work area is always clean and tidy.
Easily installed in shaker room.
Reviews
MOONSOON was easy to install. Plug in with HP washer and electric power.
Screens are washed in 30 sec.
Very easy to use do to one start and push button. High HSE benefitsRig manager - Archer
Rental
RIGTOOLS can provide rental of the MONSOON Shaker Screen Cleaner.
MONSOONS for rent are a stock item at RIGTOOLS.
Video
We can provide a suitable HP Cleaner for your MONSOON Shaker Screen Washer / COBRA Wash & Dope Tool / TYPHOON Wiper / BHA Wash Tool / SPEEDY Gonzales Pin Cleaner.
The high level of safety in today’s drilling operations around the world require special attention to
equipment. Most drilling rigs have fully automated derrick and pipe handling systems. In certain
regions the legislation prohibits personnel to work on the drill floor while the automatic pipe
handling machines are in use. But still we experience personnel using HP cleaners when BHA is
pulled through rotary.
Facts
The tool is tailor-made to fit on top of the diverter or bell nipple. It connects to the rig’s HP system or a special HP unit fit for purpose. Actuation of HP water can be done locally on the drill floor or remotely from driller’s cabin.
The BHA Wash Tool can be installed either with three legged sling or with the special made Running Tool.
BHA Wash Tool is welded in heavy stainless steel and in compliance with “Dropped Object Prevention Handbook”.
CE certification.
Welding certificate.
Advantages
Easy to install on top of diverter or bell nipple.
Improves safety on drill floor.
No risk of dropped objects.
No debris on drill floor or windows from using manual HP cleaning. All debris will be kept below rotary. Clean and tidy.
BHA will be pulled faster out of hole, no stops for manual HP cleaning.
Clean BHA when racking back or laying down on deck.
Benefits
BHA Wash Tool eliminates personnel using manual HP cleaners in Red Zone when BHA etc. is pulled through rotary.
No exposure to the danger of dropped objects or working close to remote operated machines on drill floor.
The tool only uses very limited water volume when HP cleaning the BHA.
Less time spent on housekeeping after tripping, fast moving to next operation, less flat spots on operational trends.
Reviews
we have really good experience with this washer Performance Coach - Valaris Viking
The BHA wash tool has worked as intended. In my opinion this is a step in the right direction that every drilling rig should consider. It enables us to stay in compliance with red zone requirements without compromising the quality of the craftsmanship on the rig floor. We keep the floor clean while pulling BHA, which is a HSE benefit as a slippery deck represents a risk. It saves time, not having to stop and clean BHA for every couple of meters. The deck crew is also happy, as the string components coming out are cleaner than before.Roger Løvslett, Operations Planner -- TRANSOCEAN SEARCHER
Vis jeg er i Stavanger, kommer jeg innom dere på Stand over en kopp kaffe og ønsker gledelig å se over deres nye produkter, for å nevne det, er vi meget fornøyde med deres Rotary wash unit (BHA Wash Tool) !Kenneth Aske, Optimizer Onshore, Statoil/NAD -- NORTH ATLANTIC DRILLING - WEST EPSILON
We can provide a suitable HP Cleaner for your MONSOON Shaker Screen Washer / COBRA Wash & Dope Tool / TYPHOON Wiper / BHA Wash Tool / SPEEDY Gonzales Pin Cleaner.
Experience increased safety and efficiency based on unique high quality equipment and solutions.
Choose from a variety of patented solutions to implement higher standards in your drilling operation.
We can modify our standard tools to ensure an exact fit on your rig and functioning interface.
Based on your requirements we can also tailor-make a one-off solution that once and for all solves your everyday drilling problem.
To our daily users of RIGTOOLS every minute and every safety precaution is most important and the key to successful oil field operations.
